Re: [squid-users] Is it possible to mark tcp_outgoing_mark (server side) with SAME MARK as incoming packet (client side)?

On 03/15/2014 05:11 PM, Amos Jeffries wrote:

> On 15/03/2014 6:46 p.m., Amm wrote:
>> I would like to mark outgoing packet (on server side) with SAME MARK as on incoming (NATed or CONNECTed) packet.

> http://www.squid-cache.org/Doc/config/qos_flows/
>
> Squid default action is to pass the netfilter MARK value from client
> through to the server. All you should need to do is *omit*
> tcp_outgoing_mark directives from changing it to something else.
>
> Amos

Oh that's great, thanks, I did not know this.

However, I tried this but somehow I am not able to get it working

Please let me know what could be wrong.

First I thought it may be because netfilter-conntrack-devel was not
installed. So I installed the same.

Then I recompiled squid with these:
--with-netfilter-conntrack and --with-libcap

configure: ZPH QOS enabled: yes
configure: QOS netfilter mark preservation enabled: yes
...
checking for operational libcap2 headers... yes
configure: libcap support enabled: yes
configure: libcap2 headers are ok: yes
...
configure: Linux Netfilter support requested: yes
configure: Linux Netfilter Conntrack support requested: yes
checking for library containing nfct_query... -lnetfilter_conntrack
(4-5 more lines with header check with answer yes)

Installed new squid and restarted squid.

Ran following iptables command for debugging:

# CMD 1- mark all packets coming from 192.168.1.45
$ iptables -t mangle -I PREROUTING -s 192.168.1.45 -j MARK --set-mark 0x112

# CMD 2 - count packets/bytes going OUT on port 80 and marked 0x112
$ iptables -t mangle -I POSTROUTING -m mark --mark 0x112 -p tcp --dport 80

# CMD 3 - NAT settings (intercept)
$ iptables -t nat -nvL

Chain PREROUTING (policy ACCEPT 22610 packets, 2251K bytes)
  pkts bytes target prot opt in out source
destination
   347 21371 REDIRECT tcp -- eth0 * 0.0.0.0/0
0.0.0.0/0 tcp dpt:80 redir ports 3128

Some settings in /etc/squid/squid.conf:

http_port 3128 intercept

# log for nfmark logging
logformat nfmark %ts.%03tu %6tr %>a %Ss/%03>Hs %<st %rm %ru %[un %Sh/%<a
%mt %>nfmark %<nfmark

access_log daemon:/var/log/squid/access.log squid all
access_log daemon:/var/log/squid/nfmark.log nfmark all

(Do I need to put anything else in squid.conf for marking?)
(There is no tcp_outgoing_mark)

Now I accessed Google from 192.168.1.45

$ tail /var/log/squid/nfmark.log

1394891128.585 403 192.168.1.45 TCP_MISS/200 21137 GET
http://www.google.co.in/?xxx - HIER_DIRECT/173.194.36.56 text/html 0x0 0x0
1394891128.793 92 192.168.1.45 TCP_MISS/304 393 GET
http://www.google.co.in/images/srpr/mlogo2x_3.png -
HIER_DIRECT/173.194.36.56 - 0x0 0x0
1394891128.851 115 192.168.1.45 TCP_MISS/304 393 GET
http://www.google.co.in/images/logo_mobile_srp_3.png -
HIER_DIRECT/173.194.36.56 - 0x0 0x0

nfmark in and out both are logged as 0x0 whereas I was expecting atleast
one of them to be 0x112

$ iptables -t mangle -nvL PREROUTING

Chain PREROUTING (policy ACCEPT 1590 packets, 604K bytes)
  pkts bytes target prot opt in out source
destination
   135 22042 MARK all -- * * 192.168.1.45
0.0.0.0/0 MARK set 0x112

$ iptables -t mangle -nvL POSTROUTING

Chain POSTROUTING (policy ACCEPT 1653 packets, 372K bytes)
  pkts bytes target prot opt in out source
destination
     0 0 tcp -- * * 0.0.0.0/0
0.0.0.0/0 mark match 0x112 multiport dports 80,443

PREROUTING shows 135 packets MARKed as 0x112 but POSTROUTING shows no
packets marked.

What could be wrong?

Thanks in advance.

Amm
